Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
35TXW820MEFC8X50CAP ALUM 820UF 20% 35V RADIAL |
2,172 | - |
|
Datasheet |
Bulk | TXW | Active | 820 µF | ±20% | 35 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.82 A @ 120 Hz | 3.04 A @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
16ZLJ3300MG412.5X30CAP ALUM 3300UF 20% 16V RADIAL |
3,375 | - |
|
Datasheet |
Tape & Box (TB) | ZLJ | Active | 3300 µF | ±20% | 16 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.562 A @ 120 Hz | 3.66 A @ 100 kHz | 18 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.260 (32.00mm) | - | Through Hole |
|
400BXC22MEFC16X20CAP ALUM 22UF 20% 400V RADIAL |
2,782 | - |
|
Datasheet |
Bulk | BXC | Active | 22 µF | ±20% | 400 V | - | 12000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 304 mA @ 120 Hz | 760 mA @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
400BXC22MEFCGC16X20CAP ALUM 22UF 20% 400V RADIAL |
3,184 | - |
|
Datasheet |
Tape & Box (TB) | BXC | Active | 22 µF | ±20% | 400 V | - | 12000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 304 mA @ 120 Hz | 760 mA @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
10PK10000MEFCGC16X25CAP ALUM 10000UF 20% 10V RADIAL |
3,574 | - |
|
Datasheet |
Tape & Box (TB) | PK | Active | 10000 µF | ±20% | 10 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.27 A @ 120 Hz | 2.6105 A @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
100ZL270MEFC16X25CAP ALUM 270UF 20% 100V RADIAL |
3,373 | - |
|
Datasheet |
Bulk | ZL | Active | 270 µF | ±20% | 100 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 800 mA @ 120 Hz | 1.6 A @ 100 kHz | 53 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
100ZL270MEFCGC16X25CAP ALUM 270UF 20% 100V RADIAL |
3,957 | - |
|
Datasheet |
Tape & Box (TB) | ZL | Active | 270 µF | ±20% | 100 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 800 mA @ 120 Hz | 1.6 A @ 100 kHz | 53 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
10YXG5600MEFC12.5X40CAP ALUM 5600UF 20% 10V RADIAL |
3,306 | - |
|
Datasheet |
Bulk | YXG | Active | 5600 µF | ±20% | 10 V | - | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.345 A @ 120 Hz | 3.35 A @ 100 kHz | 17 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
10YXG5600MEFCG412.5X40CAP ALUM 5600UF 20% 10V RADIAL |
3,145 | - |
|
Datasheet |
Tape & Box (TB) | YXG | Active | 5600 µF | ±20% | 10 V | - | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.345 A @ 120 Hz | 3.35 A @ 100 kHz | 17 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
200BXC100MEFC16X20CAP ALUM 100UF 20% 200V RADIAL |
2,662 | - |
|
Datasheet |
Bulk | BXC | Active | 100 µF | ±20% | 200 V | - | 12000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 639 mA @ 120 Hz | 1.42 A @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
200BXC100MEFCGC16X20CAP ALUM 100UF 20% 200V RADIAL |
3,603 | - |
|
Datasheet |
Tape & Box (TB) | BXC | Active | 100 µF | ±20% | 200 V | - | 12000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 639 mA @ 120 Hz | 1.42 A @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
10ZT1500M12.5X20CAP ALUM 1500UF 20% 10V RADIAL |
3,350 | - |
|
Datasheet |
Bulk | ZT | Active | 1500 µF | ±20% | 10 V | - | 4000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | General Purpose | 860 mA @ 120 Hz | 1.72 A @ 100 kHz | 28 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
10ZT1500MG412.5X20CAP ALUM 1500UF 20% 10V RADIAL |
2,655 | - |
|
Datasheet |
Tape & Box (TB) | ZT | Active | 1500 µF | ±20% | 10 V | - | 4000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | General Purpose | 860 mA @ 120 Hz | 1.72 A @ 100 kHz | 28 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 0.866 (22.00mm) | - | Through Hole |
|
25WA2200MKC16X20CAP ALUM 2200UF 20% 25V RADIAL |
2,156 | - |
|
Datasheet |
Bulk | WA | Active | 2200 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.4 A @ 120 Hz | 1.61 A @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
16ZLH4700MEFCGC16X25CAP ALUM 4700UF 20% 16V RADIAL |
3,120 | - |
|
Datasheet |
Tape & Box (TB) | ZLH | Active | 4700 µF | ±20% | 16 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.541 A @ 120 Hz | 3.63 A @ 100 kHz | 13 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
50ZLH1000MEFCGC16X25CAP ALUM 1000UF 20% 50V RADIAL |
3,665 | - |
|
Datasheet |
Tape & Box (TB) | ZLH | Active | 1000 µF | ±20% | 50 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.806 A @ 120 Hz | - | 21 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
80ZLH390MEFCGC16X20CAP ALUM 390UF 20% 80V RADIAL |
2,075 | - |
|
Datasheet |
Tape & Box (TB) | ZLH | Active | 390 µF | ±20% | 80 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 962.5 mA @ 120 Hz | - | 58 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
63ZLH560MEFCGC16X20CAP ALUM 560UF 20% 63V RADIAL |
3,445 | - |
|
Datasheet |
Tape & Box (TB) | ZLH | Active | 560 µF | ±20% | 63 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.155 A @ 120 Hz | - | 43 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
100ZLH270MEFCG412.5X30CAP ALUM 270UF 20% 100V RADIAL |
3,001 | - |
|
Datasheet |
Tape & Box (TB) | ZLH | Active | 270 µF | ±20% | 100 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 975 mA @ 120 Hz | 1.95 A @ 100 kHz | 51 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
10ZLJ4700MG412.5X30CAP ALUM 4700UF 20% 10V RADIAL |
3,688 | - |
|
Datasheet |
Tape & Box (TB) | ZLJ | Active | 4700 µF | ±20% | 10 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.562 A @ 120 Hz | 3.66 A @ 100 kHz | 18 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.260 (32.00mm) | - | Through Hole |
