Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
UUX1C331MNL1GSCAP ALUM 330UF 20% 16V SMD |
1,153 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | UUX | Active | 330 µF | ±20% | 16 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 441 mA @ 120 Hz | 573.3 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
UPJ1V221MPD6TDCAP ALUM 220UF 20% 35V RADIAL |
1,352 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPJ | Not For New Designs | 220 µF | ±20% | 35 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 560 mA @ 120 Hz | 770 mA @ 10 kHz | 140 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.650 (16.50mm) | - | Through Hole |
|
UFG1V101MPM1TDCAP ALUM 100UF 20% 35V RADIAL |
1,695 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UFG | Not For New Designs | 100 µF | ±20% | 35 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 176 mA @ 120 Hz | 264 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.551 (14.00mm) | - | Through Hole |
|
UVK2A680MPD1TDCAP ALUM 68UF 20% 100V RADIAL |
1,094 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UVK | Not For New Designs | 68 µF | ±20% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 270 mA @ 120 Hz | 540 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.551 (14.00mm) | - | Through Hole |
|
UZT1E100MCL1GBCAP ALUM 10UF 20% 25V SMD |
1,498 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | UZT | Active | 10 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | - | - | General Purpose | 20 mA @ 120 Hz | 30 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.181 (4.60mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
UPM1V181MPD6TDCAP ALUM 180UF 20% 35V RADIAL |
1,102 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPM | Not For New Designs | 180 µF | ±20% | 35 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 500 mA @ 120 Hz | 700 mA @ 10 kHz | 110 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.669 (17.00mm) | - | Through Hole |
|
UPV1C820MGD1TDCAP ALUM 82UF 20% 16V RADIAL |
1,875 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPV | Not For New Designs | 82 µF | ±20% | 16 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | - | - | General Purpose | - | - | 710 mOhms | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
UPM1K560MPD6TDCAP ALUM 56UF 20% 80V RADIAL |
1,469 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPM | Not For New Designs | 56 µF | ±20% | 80 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 305 mA @ 120 Hz | 500 mA @ 10 kHz | 360 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.669 (17.00mm) | - | Through Hole |
|
UPM2D3R3MPD1TDCAP ALUM 3.3UF 20% 200V RADIAL |
1,219 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPM | Not For New Designs | 3.3 µF | ±20% | 200 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 50 mA @ 120 Hz | 80 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.571 (14.50mm) | - | Through Hole |
|
UKW1C331MPD1TDCAP ALUM 330UF 20% 16V RADIAL |
1,911 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UKW | Not For New Designs | 330 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 360 mA @ 120 Hz | - | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
UPM1J820MPD1TDCAP ALUM 82UF 20% 63V RADIAL |
2,290 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPM | Not For New Designs | 82 µF | ±20% | 63 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 385 mA @ 120 Hz | 600 mA @ 10 kHz | 150 mOhms | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.846 (21.50mm) | - | Through Hole |
|
UPW1A102MPD6TDCAP ALUM 1000UF 20% 10V RADIAL |
1,518 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPW | Not For New Designs | 1000 µF | ±20% | 10 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 746.25 mA @ 120 Hz | 995 mA @ 100 kHz | 65 mOhms | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
UKT1A471MPD1TDCAP ALUM 470UF 20% 10V RADIAL |
1,985 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UKT | Not For New Designs | 470 µF | ±20% | 10 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | - | Audio | 280 mA @ 120 Hz | 420 mA @ 10 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
UHD1V471MPD1TDCAP ALUM 470UF 20% 35V RADIAL |
1,001 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UHD | Not For New Designs | 470 µF | ±20% | 35 V | - | 4000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.365 A @ 120 Hz | 1.82 A @ 100 kHz | 23 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
UVZ2V100MPD1TDCAP ALUM 10UF 20% 350V RADIAL |
1,279 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UVZ | Not For New Designs | 10 µF | ±20% | 350 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 80 mA @ 120 Hz | 128 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
UPJ0J122MHD6TOCAP ALUM 1200UF 20% 6.3V RADIAL |
1,374 | - |
|
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPJ | Not For New Designs | 1200 µF | ±20% | 6.3 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 835 mA @ 120 Hz | 950 mA @ 10 kHz | 120 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 0.650 (16.50mm) | - | Through Hole |
|
UWG1V470MCL1GSCAP ALUM 47UF 20% 35V SMD |
1,900 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | UWG | Active | 47 µF | ±20% | 35 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | AEC-Q200 | General Purpose | 115 mA @ 120 Hz | 230 mA @ 100 kHz | 400 mOhms | - | 0.315 Dia (8.00mm) | 0.256 (6.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
UZG1H2R2MCL1GBCAP ALUM 2.2UF 20% 50V SMD |
1,994 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | UZG | Active | 2.2 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | - | - | General Purpose | 9.6 mA @ 120 Hz | 14.4 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.156 (3.95mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
UZG1HR47MCL1GBCAP ALUM 0.47UF 20% 50V SMD |
1,877 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | UZG | Not For New Designs | 0.47 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | - | - | General Purpose | 3.3 mA @ 120 Hz | 4.95 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.156 (3.95mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
UZG1HR33MCL1GBCAP ALUM 0.33UF 20% 50V SMD |
1,633 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | UZG | Not For New Designs | 0.33 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | - | - | General Purpose | 2.8 mA @ 120 Hz | 4.2 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.156 (3.95mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
