Renesas Electronics America Inc RJM0603JSC-00#13

RJM0603JSC-00#13
Part No.:
RJM0603JSC-00#13
Manufacturer:
Renesas Electronics America Inc
Category:
Transistors - FETs, MOSFETs - Arrays
Package:
20-SOIC (0.433, 11.00mm Width) Exposed Pad
Datasheet:
RJM0603JSC-00#13.pdf
Description:
MOSFET 3N/3P-CH 60V 20A HSOP
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Product Comparison
  • Related Categories
Packaging:
-
Series:
Automotive, AEC-Q101
ProductStatus:
Obsolete
FETType:
3 N and 3 P-Channel (3-Phase Bridge)
FETFeature:
Logic Level Gate, 4.5V Drive
DraintoSourceVoltage(Vdss):
60V
Current-ContinuousDrain(Id)@25°C:
20A
RdsOn(Max)@IdVgs:
20mOhm @ 10A, 10V
Vgs(th)(Max)@Id:
2.5V @ 1mA
GateCharge(Qg)(Max)@Vgs:
43nC @ 10V
InputCapacitance(Ciss)(Max)@Vds:
2600pF @ 10V
Power-Max:
54W
OperatingTemperature:
175°C
MountingType:
Surface Mount
Category:
Transistors - FETs, MOSFETs - Arrays
Datasheet:
Shenzhen Shinyua Technology Co., Ltd.RJM0603JSC-00#13.pdf
